SPECIFICATIONS
Number of channels: 8, true color screen voltage display,
RS232 central control system control, intelligent type,
Single channel power capacity with soft drive: 220V/30A timing
Switching intermittent time: The control can be set at will: SEQUENCY ON/OFF-LOCK SWITCH BYPASS/NORMAL-BUTTON
Power supply: 220V/50Hz-60Hz STANDARD 3-WIRE, GROUNDED WIRE IS NEEDED
Product/transport size: 482x225x44(510x290x120)mm
Net weight/gross weight: 4.0kg/5.1kg
| Product Model | Q10 |
| Frequency response range (-1dB) | 20Hz-50KHz(MUSIC MIC) |
| Input sensitivity | 11MV(MIC)210MV(MUSIC) |
| Main channel tone (±10dB) | 5- parametric equalization |
| Subwoofer (±10dB) | 3-parametric equalization |
| Center tone (±10dB) | 5- parametric equalization |
| Rear tone (±10dB) | 5- parametric equalization |
| Music tone (±10dB) | 10- parametric equalization |
| Microphone A tone (±10dB) | 15-parameter equalization |
| Microphone B tone (±10dB) | 15-parameter equalization |
| Microphone low cut | 0Hz-330Hz |
| Signal to noise ratio (SNR) | ≥95dB |
