Mô tả
| Model | QSC-10 | QSC-112 | QSC-115 | QSC-215 |
| LF Driver | 1×10″ (250mm) | 1×12″ (300mm) | 1×15″ (380mm) | 2×15″ (380mm) |
| HF Driver | 1×1.7″ (44mm) | 1×1.7″ (44mm) | 1×1.7″ (44mm) | 1×3″ (75mm) |
| Frequency range(±3dB) | 68Hz-20kHz | 50Hz-20kHz | 50Hz-20kHz | 48HZ-20KHz |
| Rate Power(RMS) | 250W | 300W | 400W | 800W |
| MAX Power(PEAK) | 1000W | 1200W | 1600W | 3200W |
| Sensitivity (dB/1M/1W) | 95dB | 97dB | 99dB | 101dB |
| MAX SPL(PEAK/1M) | 127dB | 128dB | 1600dB | 1600dB |
| Coverage Pattern | Vertical 60˚, Horizontal 80˚ | Vertical 60˚, Horizontal 80˚ | Vertical 60˚, Horizontal 80˚ | Vertical 60˚, Horizontal 80˚ |
| Nominal impedance | 8 Ω | 8 Ω | 8 Ω | 4 Ω |
| Dimensions(H*W*D) | 548*355*317 | 650*385*375 | 760*443.4*408 | 1100*502*468 |
| Net Weight | 13.5kg | 21.6kg | 28.7kg | 50.65 kg |
